Refrigerator Mold
Details
Model：
Booling-Refrigerator Mold-1
Mold Steel:
45#, P20, 718, 2738, H13, SKD11, S136, 7075AL, 6065AL, beryllium bronze, etc.
Plastic Material:
PP/PE
Mold Base:
LKM, Booling standard
Origin：
China
Booling’s refrigerator molds are made of food-grade materials and can directly produce low-temperature resistant refrigerator products that ensure hygienic manufacturing standards. We provide a full range of refrigerator mold production, including models for home use, commercial use, freezers, smart refrigerators, etc., and provide manufacturers with production solutions for various refrigerator parts, such as liners, door strips, bases, drawers, etc. We combine CAD drawing software with advanced processing equipment to achieve precise processing of complex shapes and components. All refrigerator molds have been repeatedly tested to obtain an error within ±0.02mm to achieve high-precision manufacturing.
Application：
- Refrigerator
- Injection Molding
Related Hot Products
Technical Parameters Of Refrigerator Mold
Booling uses digital software design platforms such as UG to adjust the structural parameters of refrigerator molds at any time and verify the rationality of the design.
| Number of cavities | 1 or multi-cavity |
|---|---|
| Process type | Injection molding, blow molding |
| Steel hardness | HRC28-HRC60 |
| Mold heat treatment | Vacuum quenching, tempering, nitriding, etc. |
| Mold life | 500,0000-2,000,000 times |
| Mold size | Depends on refrigerator design and injection machine |
| Mold weight | Depends on refrigerator design and injection machine |
| T1 | 30-60 days |
| Processing method | Grinding machine, drilling machine, CNC, EDM, high-speed finishing, deep hole drilling, wire cutting, etc. |
| Design software | AutoCAD, UG, Moldflow |
| 3D drawing format | Stp, x-t, prt, etc. |
| Injection runner | Cold runner/hot runner |
| Injection gate | Direct gate, point gate, latent gate, fan gate, bull-horn gate, etc. |
| Sample quantity | 3-5 pieces |
| Processable surface roughness | 0.8μm |
| Dimensional accuracy | ±0.02mm |
| Quotation method | Send samples, send sample pictures and dimensions, refrigerator 3D drawings. |
| Mold packaging | Wooden box |
| Mold accessories | Free |
| MOQ | 1 piece |
| Ejection method | Ejector, stripper, etc. (using hydraulic, cylinder, air valve, etc.) |
| Price Term | FOB, CIF |
FAQ for Air Refrigerator Mold
There are many types of refrigerator molds, mainly including door shells, top covers, freezer storage boxes, etc. Booling needs to consider multiple factors such as material selection, process flow, precision control, etc. when designing refrigerator molds to ensure the dimensional accuracy and surface quality of refrigerator parts.
Refrigerator Mold Customization Service
Booling provides customized services for refrigerator molds. Professional designers will provide reasonable molds to shorten processing time.
1. Use advanced laser engraving technology or EDM to engrave the logo on the mold surface. It is also possible to make multiple logos for inlay, which is convenient for customers’ ODM production. The mold cavity can be replaced, which makes it more convenient to replace the logo and trademark.
2. Customize the surface effect of the refrigerator, such as polished surface, sandblasting, simulated leather texture, etc., and can also be customized according to samples, such as micro patterns, three-dimensional printing, etc., to form a modern and simple style and enhance the aesthetics
3. Design the mold structure size according to the customer’s machine parameters to ensure processing smoothness and tolerance within the allowable range
4. According to the market demand for the number of refrigerator parts and the size of the parts, design the number of mold cavities and arrange them reasonably. Booling uses a hot runner system when designing the mold. Each cavity can be heated independently, and the temperature control is more precise.
5. After the mold is made, it can provide customers with product OEM production services.
6. With the help of CNC milling machines and inspection tools, the finishing accuracy of refrigerator injection molds can be controlled within 0.01mm.
7. Booling introduced rapid prototyping mold molding technology to reduce multiple steps in traditional mold processing, shorten the production cycle, and be suitable for low-volume or sample production.
How is BOOLING refrigerator mold made?
Quality monitoring and inspection of the refrigerator mold is the key to ensuring the quality of the final product and meeting production needs.
1. After the customer confirms the refrigerator mold, our Booling engineers and designers will review the design drawings to ensure that there are no errors.
2. During the CNC processing stage, Booling will continuously check and confirm various processes, such as EDM and other processes, to ensure that the tolerance of each process is within the allowable range.
3. During the mold trial stage, the mold is inspected according to the customer’s requirements and acceptance criteria for the refrigerator mold.
4. After the mold trial, the mold is optimized and adjusted.
5. Before shipment, check whether all accessories and related documents meet the standards to ensure that the mold can be used normally.
6. Within one month after receiving the goods, if there is any problem with the refrigerator mold, we can provide complete after-sales service, and you can contact us by email, phone, etc.
The processing of the refrigerator mold requires high precision, otherwise it will affect the closing of the refrigerator door or the pushing and pulling of the freezer drawer. Booling’s milling machines, wire cutting machines, grinders, and other equipment can control the accuracy to about 0.005~0.01mm to ensure the surface and size quality of the mold.
