Dustbin Mold
Details
Model：
Booling-dustbin Mold-1
Mold Steel:
45#, P20, 718, 2738, H13, SKD11, S136, 7075AL, 6065AL, beryllium bronze, etc.
Plastic Material:
PP/HDPE
Mold Base:
LKM, Booling standard
Origin：
China
The processing of the dustbin mold mainly uses a 5-axis machining center and high-speed milling, EDM, grinder processing, and other technologies to achieve precision manufacturing technology. The dustbin mold determines the design and function of it. Booling uses hot runner system technology to achieve precise temperature control, which significantly improves the molding rate and molding speed of the dustbin mold. We provide different models of dustbin molds to achieve fast delivery for various industries.
Application：
- Dustbin
- Injection Molding
Related Hot Products
Technical Parameters Of Dustbin Mold
The design of trash can molds is complex and has strict requirements on appearance. The trash can molds designed by Booling provide the best solution to the problem of garbage classification.
| Model | Booling-Dustbin Mold-1 |
|---|---|
| Number of cavities | 1 or multi-cavity |
| Process type | Injection molding, blow molding |
| Steel hardness | HRC28-HRC60 |
| Mold heat treatment | Vacuum quenching, tempering, nitriding, etc. |
| Mold life | 500,0000-2,000,000 times |
| Mold size | Depends on dustbin design and injection/blow machine |
| Mold weight | Depends on dustbin design and injection/blow machine |
| T1 | 30-60 days |
| Processing method | Grinding machine, drilling machine, CNC, EDM, high-speed finishing, deep hole drilling, wire cutting, etc. |
| Design software | AutoCAD, UG, Moldflow |
| Injection runner | Cold runner/hot runner |
| Injection gate | Direct gate, point gate, latent gate, fan gate, bull-horn gate, etc. |
| Sample quantity | 3-5 pieces |
| Processable surface roughness | 0.8μm |
| Dimensional accuracy | ±0.02mm |
| Quotation method | Send samples, send sample pictures with dimensions, dustbin 3D drawings. |
| Mold packaging | Wooden box |
| Mold accessories | Free |
| MOQ | 1 piece |
| Ejection method | Ejector, stripper, etc. (using hydraulic, cylinder, air valve, etc.) |
| Price Term | FOB, CIF |
FAQ for Dustbin Mold
Booling can provide the most common problems in the purchase of the dustbin mold. Users can learn more about the molds through the FAQs, or contact our engineers for one-on-one communication.
Processing Technology of Dustbin Mold
The processing of the dustbin mold mainly includes two stages: rough processing and fine processing.
1. Determine the drawings and cut materials.
2. Rough processing: Booling uses large processing equipment, such as CNC milling machines, drilling machines, etc. to process the preliminary contour. The accuracy of the rough processing stage of the dustbin mold is low, in preparation for subsequent fine processing.
3. Heat treatment: Temper the dustbin mold after rough processing to improve the hardness and toughness of the mold.
4. Fine processing: Use high-precision processing equipment, such as CNC milling, engraving machines, EDM machines, etc. to fine-process the mold. Booling can ensure that the accuracy of the dustbin mold reaches ±0.01mm in this step.
5. Assembly of the mold: Booling will select the assembly reference and the assembly order of the upper and lower molds according to the function of each part, and then assemble the parts to ensure assembly accuracy.
6. Surface treatment of the dustbin mold, such as polishing, sandblasting, leather grain, etc., to ensure surface accuracy.
Advantages of Dustbin Mold Processing
Booling can customize the mold according to the capacity, function, material, etc. of the dustbin.
1. Booling can provide customized dustbin mold processing services to meet the needs of specific use environments, such as home or office places, communities, parks, stations, hospitals, shopping centers, schools, and other public places.
2. Dustbin molds support PP, HDPE, and other materials for processing, with chemical corrosion resistance and high-temperature resistance, and can be used outdoors and in some public places.
3. The molds manufactured by Booling have a long service life and can be processed in long continuous cycles.
4. During the design process, Booling’s molds can achieve rapid conversion from 2D to 3D drawing formats, with a short time to market and efficient production.
5. Provide global mold export customization services and provide English and other language support.
6. Use a variety of drawing formats, such as 2D (PDF/CAD), and 3D (STL/STP/OBJ/IGES, etc.).
Dustbin Mold Packaging Process
To ensure the accuracy of the dustbin mold, Booling will use specially customized packaging to ship.
1. Clean the core and cavity of the dustbin mold with oil
2. Spray rust inhibitor on the core and cavity
3. Spray anti-rust paint on the surface of the dustbin mold
4. Cover the mold surface with film
5. Packing of mold accessories
6. Use customized wooden boxes to pack the dustbin mold, and use foam blocks or cardboard to fill the remaining space
7. Load by sea or send to the airport for air transport
Booling optimizes the design and structure of the dustbin mold, accurately calculates the flow channel size and layout, improves production quality and speed, and meets the high-quality and efficient production of the dustbin. Booling’s dustbin molds have been exported to Germany, the United States, India, South Africa, Japan, South Korea, and other countries.
