Pet Crate Mold
Details
Model：
Booling-Pet Crate Mold-1
Mold Steel:
45#, P20, 718, 2738, H13, SKD11, S136, 7075AL, 6065AL, beryllium bronze, etc.
Plastic Material:
PP/PE
Mold Base:
LKM, Booling standard
Origin：
China
The design of the pet crate mold is complex, with multiple parting surfaces and complex demoulding mechanisms. When designing pet crate molds, it is necessary to consider the needs of pets and provide a certain degree of comfort and breathability. Booling mostly adopts rounded and chamfered designs to ensure the safety of pets while providing a large activity space to meet the requirements of pets of different sizes. We provide molds for pet airline crates, travel boxes, and other models to meet the needs of different manufacturers.
Application：
- Pet Crate
- Injection Molding
Related Hot Products
Technical Parameters Of Pet Crate Mold
The pet crate molds manufactured by Booling combine appearance and practicality with high precision and safety, suitable for the life and transportation of pets.
| Number of cavities | 1 or multi-cavity |
|---|---|
| Process type | Injection molding |
| Steel hardness | HRC28-HRC60 |
| Mold heat treatment | Vacuum quenching, tempering, nitriding, etc. |
| Mold life | 500,0000-2,000,000 times |
| Mold size | Depends on pet crate design and injection machine |
| Mold weight | Depends on pet crate design and injection machine |
| T1 | 30-60 days |
| Processing method | Grinding machine, drilling machine, CNC, EDM, high-speed finishing, deep hole drilling, wire cutting, etc. |
| Design software | AutoCAD, UG, Moldflow |
| Injection runner | Cold runner/hot runner |
| Injection gate | Direct gate, point gate, latent gate, fan gate, bull-horn gate, etc. |
| Sample quantity | 3-5 pieces |
| Processable surface roughness | 0.8μm |
| Dimensional accuracy | ±0.02mm |
| Quotation method | Send samples, send sample pictures and dimensions, pet crate 3D drawings. |
| Mold packaging | Wooden box |
| Mold accessories | Free |
| MOQ | 1 piece |
| Ejection method | Ejector, stripper, etc. (using hydraulic, cylinder, air valve, etc.) |
| Price Term | FOB, CIF |
FAQ for Pet Crate Mold
Booling can provide the most common problems in purchasing medicine pet crate mold. Users can learn more about molds through FAQ, or contact our engineers for one-on-one communication.
Performance Requirements for Pet Crate Mold
As a tool for living and transporting living things, pet crate molds need to have some special properties.
- Corrosion Resistance: The pet crate may be in direct contact with the pet’s feces and food residues, and may be disinfected at any time. It needs to have excellent corrosion resistance to prevent rust or corrosion on the surface
- Weather Resistance: It needs to have a certain weather resistance and is not affected by thermal expansion and contraction to ensure the stability of quality
- Wear resistance: The pet crate has a certain wear resistance to prevent pet scratches from affecting product quality. In addition, the processing mold also needs to choose steel with a certain wear resistance to ensure that the mold can withstand frequent opening and closing of the mold
- Dimensional Stability: During long-term use, the mold should remain stable and will not affect the processing accuracy of the pet crate due to factors such as aging and wear of the material
- High Precision: Since the pet crate needs to be matched with other metal products, it needs to have a higher precision to ensure the subsequent assembly accuracy
Processing Requirements for Pet Crate Mold
The structure of pet crate molds is special and complex. Booling designers will carefully study every detail and structure to ensure the production of high-quality products.
- The pet crate has multiple irregular surfaces and internal structures, and the design of the parting surface is relatively complex to ensure that the plastic melt can evenly fill every corner of the cavity
- The pet crate is large in size and is prone to uneven wall thickness defects during processing. Booling optimizes the mold cooling system, increases the diameter and number of cooling water channels, reduces product internal stress, and avoids deformation
- To ensure the transportation and life safety of pets, pet crate molds mostly use rounded and chamfered designs, which will greatly increase the difficulty of demolding. Booling uses more efficient demolding mechanisms, such as push plate demolding, slider demolding, etc., to improve demolding rate and demolding integrity
- The pet crate has high requirements for appearance. Booling will conduct strict quality inspection and performance optimization, such as precision, hardness, surface roughness, etc. Test molds are carried out to continuously optimize process parameters, mold structure, etc. to produce high-quality pet crate products
